The Classic Sunshine Glass Greenhouse (Sunlight Greenhouse Classic Model) represents the evolution of high-performance horticulture architecture. Designed with a Venlo-inspired glass roof system and enhanced sunlight geometry, this Venlo Glass Greenhouse integrates Aluminum gutter venlo glass greenhouse technology to deliver superior light distribution, thermal retention, and structural durability. Whether for commercial vegetable production, floriculture, or research applications, the Sunshine Classic Glass Greenhouse provides growers with a reliable, all-season cultivation environment. Its modular multi-span design allows easy integration with shading,通风, and hydroponic systems, making it a go-to solution for modern agribusinesses worldwide.
Built by Henan Qincheng Agrotechnology Co., Ltd. — a leading manufacturer of Greenhouse aluminum accessories and complete protected cropping systems — the Classic Sunshine model combines traditional glasshouse aesthetics with advanced engineering. From high wind load resistance to optimal light transmittance (up to 92%), it ensures year-round productivity and reduces energy consumption.
Structure Specifications
• Span width: 9.6m / 10.8m / 12.0m (customizable)
• Bay spacing: 4.0m / 5.0m
• Gutter height: 4.0m – 6.5m (adjustable based on crop)
• Roof slope: 22° – 25° (optimized for sunlight penetration)
• Glass type: 4mm tempered glass / 5mm anti-reflective coated horticultural glass
• Framework material: Hot-dip galvanized steel (Q235B, 275g/m² zinc coating) + aluminum alloy gutters
• Load capacity: Snow load ≤ 0.45 kN/m², wind load ≤ 0.6 kN/m²
• Light transmittance: ≥91.5% (standard clear glass) ·
• Thermal insulation: Double-layer glass option available; aluminum thermal break profiles
• Ventilation: Continuous rack-and-pinion roof vents (both sides) + side roll-up windows
• Shading system: External woven shade + internal aluminum energy-saving screen
Optional Equipment
– Hydroponic troughs & ebb-and-flow benches
– Fan & pad evaporative cooling system
– Heating system (hot water pipe / unit heaters)
– Automated climate control (Priva / Hoogendoorn compatible)
Note: Technical parameters can be modified according to local climate regulations and crop requirements.
The Classic Sunshine Glass Greenhouse adopts a venlo-style roof with asymmetrical ridge orientation to maximize early-morning and winter light capture. The glass panels have high light diffusion (patented coating optional) to eliminate shadows and promote uniform crop growth. This design reduces artificial lighting costs by up to 30%.
Unlike traditional steel gutters, we utilize aluminum gutter venlo glass greenhouse technology — extruded aluminum alloy gutters that are corrosion-resistant, lightweight, and seamlessly connect roof spans. Combined with hot-dip galvanized steel columns, the structure supports extreme weather while reducing maintenance. Moreover, we supply complete greenhouse aluminum accessories including profiles, clips, and fasteners for easy assembly.
The greenhouse includes a dedicated ridge ventilation system (motorized rack-and-pinion) and roll-up side curtains for natural airflow. Equipped with insect screens and fogging systems, it creates an optimal growing environment even in humid or hot regions. The compatibility with Multi-Span Film Greenhouse side cladding (flexible film insulation) offers extra protection during cold nights.
Double-glazed tempered glass and internal thermal screens reduce heat loss by 40%. The structure enables precise CO₂ enrichment and integrated pest management. Growers achieve earlier harvests and higher quality produce — tomatoes, cucumbers, peppers, and cut flowers thrive under this classic sunshine design.
As your farm grows, the Classic Sunshine model supports lateral extensions. The aluminum gutter connection system can be coupled with Polycarbonate sheet greenhouse sidewalls or even attached to existing multi-span film houses. This modularity future-proofs your investment.
Pro tip: Winter operation — keep internal thermal screen closed at night; summer use shade cloth + roof vents for passive cooling.
The versatility of the Classic Sunshine Glass Greenhouse makes it suitable for diverse climates and cropping systems:
One of our clients in the Netherlands reported a full return on investment within 18 months after switching to our Classic Sunshine Glass Greenhouse. With consistent production and lower heating bills, their profitability improved remarkably.
Henan Qincheng Agrotechnology Co., Ltd. provides fully customizable Venlo glass greenhouse solutions. We understand that every farm has unique requirements, so we offer:
Whether you need a small-scale research glasshouse or a 10-hectare commercial farm, we supply turnkey design, manufacturing, and installation guidance.
At Henan Qincheng, we adhere to rigorous quality protocols. The production process for Classic Sunshine Glass Greenhouse includes:
All products undergo load simulation testing according to local snow/wind loads. We provide 10-year structural warranty and 2-year on electrical and moving parts.
A: Unlike Single-span film greenhouse or simple poly tunnels, the Venlo-style glasshouse with aluminum gutters provides higher light transmission, better load capacity, and superior climate uniformity. It's ideal for year-round commercial production.
A: Absolutely. The aluminum gutter connection system is compatible with film or polycarbonate side coverings. Many growers use a glass roof for main crop area and film side sections for nursery or storage.
A: We provide standard foundation drawings – reinforced concrete point footings or strip footing depending on soil condition. Our engineering team supports design.
A: Yes. While manual operation is possible, we strongly recommend motorized rack-and-pinion vents and automatic shade curtains for precise climate control – which significantly reduces labor cost.
A: Aluminum gutter venlo glass greenhouse construction eliminates rusting, reduces weight, and simplifies installation. Aluminum also has superior thermal performance (less condensation). Combined with our greenhouse aluminum accessories, the sealing is long-lasting.
A: Yes. We support sample projects (minimum 500m² area) and can provide CAD design and professional consultation at early stage.
“Henan Qincheng’s Classic Sunshine Glass Greenhouse exceeded our expectations. After switching to their Venlo glasshouse with aluminum gutters, our tomato yield increased by 27% while heating expenses dropped by 32%. The structure survived a 110 km/h storm without any damage. Their pre-sales support and customization were top-notch.”
— GreenFuture Farms Ltd., Poland
“We combined the Classic Sunshine Glass sections with our existing multi-span film greenhouse. The integration went smoothly thanks to Qincheng’s aluminum adapters. Our roses now have longer stems and less Botrytis. The natural light environment is spectacular.”
— East Africa Horticulture Exporters, Kenya
“We’re a research institute requiring precise climate control. The Sunshine Classic model with double glass and thermal screens gave us ±0.5°C accuracy. The engineering quality of the greenhouse aluminum accessories and frames reduced assembly time by 20% compared to previous suppliers.”
— Nordic AgriTech Center, Sweden
More than 200+ commercial greenhouses worldwide rely on Henan Qincheng’s expertise in Venlo glass greenhouse and aluminum gutter venlo glass greenhouse systems. Our commitment to quality, durability, and crop-centric design ensures your project is a long-term success.
Explore our full product range: Multi-span film greenhouse | Single-span film greenhouse | Polycarbonate sheet greenhouse | Greenhouse aluminum accessories. For a personalized quote or technical drawing request for the Classic Sunshine Glass Greenhouse, contact our export team.
*Specifications subject to change based on site conditions. All performance data typical based on controlled tests. Images for illustration purposes – final design certified per order.
